Q/Quadriceps Angle Knee Injuries In Women Athletes

The Q or quadriceps angle is a measurement of pelvic width that is believed to contribute to the risk of sports injuries in women athletes. Can non-surgical therapies and exercises help rehabilitate injuries?

Quadriceps Q – Angle Injuries

The Q angle is the angle where the femur/upper leg bone meets the tibia/lower leg bone. It is measured by two intersecting lines:

• One from the center of the patella/kneecap to the anterior superior iliac spine of the pelvis.
• The other is from the patella to the tibial tubercle.
• On average the angle is three degrees higher in women than men.
• Average 17 degrees for women and 14 degrees for men. (Ramada R Khasawneh, et al., 2019)
• Sports medicine experts have linked a wider pelvis to a larger Q-angle. (Ramada R Khasawneh, et al., 2019)

Women have biomechanical differences that include a wider pelvis, making it easier to give birth. However, this difference can contribute to knee injuries when playing sports, as an increased Q angle generates more stress on the knee joint, as well as leading to increased foot pronation.

Injuries

Various factors can increase the risk of injury, but a wider Q angle has been linked to the following conditions.

Patellofemoral Pain Syndrome

• An increased Q angle can cause the quadriceps to pull on the kneecap, shifting it out of place and causing dysfunctional patellar tracking.
• With time, this can cause knee pain (under and around the kneecap), and muscle imbalance.
• Foot orthotics and arch supports could be recommended.
• Some researchers have found a link, while others have not found the same association. (Wolf Petersen, et al., 2014)

Chondromalacia of the Knee

• This is the wearing down of the cartilage on the underside of the kneecap.
• This leads to degeneration of the articular surfaces of the knee. (Enrico Vaienti, et al., 2017)
• The common symptom is pain under and around the kneecap.

ACL Injuries

• Women have higher rates of ACL injuries than men. (Yasuhiro Mitani. 2017)
• An increased Q angle can be a factor that increases stress and causes the knee to lose its stability.
• However, this remains controversial, as some studies have found no association between the Q angle and knee injuries.

Chiropractic Treatment

Strengthening Exercises

• ACL injury prevention programs designed for women have resulted in reduced injuries. (Trent Nessler, et al., 2017)
• The vastus medialis obliquus or VMO is a teardrop-shaped muscle that helps move the knee joint and stabilize the kneecap.
• Strengthening the muscle can increase the stability of the knee joint.
• Strengthening may require a specific focus on muscle contraction timing.
• Closed-chain exercises like wall squats are recommended.
• Glute strengthening will improve stability.

Stretching Exercises

• Stretching tight muscles will help relax the injured area, increase circulation, and restore range of motion and function.
• Muscles commonly found to be tight include the quadriceps, hamstrings, iliotibial band, and gastrocnemius.

Foot Orthotics

• Custom-made, flexible orthotics decrease the Q angle and reduce pronation, relieving the added stress on the knee.
• A custom orthotic ensures that the foot and leg dynamics are accounted for and corrected.
• Motion-control shoes can also help correct overpronation.

---

Knee Rehabilitation

---

References

Khasawneh, R. R., Allouh, M. Z., & Abu-El-Rub, E. (2019). Measurement of the quadriceps (Q) angle with respect to various body parameters in young Arab population. PloS one, 14(6), e0218387. doi.org/10.1371/journal.pone.0218387

Petersen, W., Ellermann, A., Gösele-Koppenburg, A., Best, R., Rembitzki, I. V., Brüggemann, G. P., & Liebau, C. (2014). Patellofemoral pain syndrome. Knee surgery, sports traumatology, arthroscopy: Official journal of the ESSKA, 22(10), 2264–2274. doi.org/10.1007/s00167-013-2759-6

Vaienti, E., Scita, G., Ceccarelli, F., & Pogliacomi, F. (2017). Understanding the human knee and its relationship to total knee replacement. Acta bio-medica : Atenei Parmensis, 88(2S), 6–16. doi.org/10.23750/abm.v88i2-S.6507

Mitani Y. (2017). Gender-related differences in lower limb alignment, range of joint motion, and the incidence of sports injuries in Japanese university athletes. Journal of Physical Therapy Science, 29(1), 12–15. doi.org/10.1589/jpts.29.12

Nessler, T., Denney, L., & Sampley, J. (2017). ACL Injury Prevention: What Does Research Tell Us? Current reviews in musculoskeletal medicine, 10(3), 281–288. doi.org/10.1007/s12178-017-9416-5
